Show pagesourceOld revisionsBacklinksBack to top × Table of Contents Linksys WAP300N Versions Hardware Highlights Flash Layout Failsafe mode Buttons Hardware Info Photos Opening the case Serial JTAG Debricking Bootloader Mods OEM info Bootlogs OEM bootlog OpenWrt bootlog Notes Tags Linksys WAP300N Linksys WAP300N simple wireless router which has 2 detachable antennas and 1 LAN connection. Currently SoC is not supported but there is a work in progress. Versions Version/Model Launch Date S/N OpenWrt Version Supported Model Specific Notes v1 201X-XX - - - NOTE: Anything not included in model specific notes, or where a short comment couldn't be included on the notes. Hardware Highlights Ver CPU Ram Flash Network Wireless USB Serial JTag Wiki FCC v1 Ralink RT6856F 64MiB 8MiB 1x WAN RT5592 No Yes notes Q87-WAP300N Manufacturer's site: http://www.linksys.com/ Forum: https://forum.openwrt.org/viewtopic.php?id=??? Flash Layout Layer0 raw flash Layer1 Bootloader Config Factory Kernel Layer2 U-Boot 1.1.3 LZMA uImage Layer3 kernel + LZMA cpio rootfs + stuff Specific values you need Bootloader tftp client IPv4 address 192.168.1.1 Firmware tftp image um_factory_fw.bin TFTP Transfer Window FILL-IN seconds TFTP Window Start approximately FILL-IN seconds after power on TFTP Server Required IP Address 192.168.1.100 Failsafe mode → failsafe_and_factory_reset Buttons → hardware.button on howto use and configure the hardware button(s). The Linksys WAP300N has two buttons. They are Reset and Secure Easy Setup. Here, we merely name the buttons, so we can use them in the above Howto: BUTTON Event Reset reset Secure Easy Setup ses Hardware Info Instruction set: MIPS Vendor: MediaTek bootloader: U-Boot / redboot / cfe / … System-On-Chip: Ralink RT6856F CPU @Frq MIPS @700MHz MIPS24KEc Flash size: 8192 KiB Flash Chip: MX25L64 RAM size: 64 MiB RAM Chip: EM68B16 Wireless No1: RT5592N Modem: none USB: NO Serial: Yes JTAG: Probably Yes Photos Model Number Front: Photo of front of the casing Back: Photo of back of the casing Opening the case Note: This will void your warranty! To remove the cover remove 3 plastic bumpers back of the device and screws. Main PCB Photo of PCB https://fccid.io/png.php?id=3188787&page=1 Serial → port.serial general information about the serial port, serial port cable, etc. How to connect to the Serial Port of this specific device: Photo of PCB with markings JTAG → port.jtag general information about the JTAG port, JTAG cable, etc. How to connect to the JTAG Port of this specific device: Photo of PCB with markings Debricking → generic.debrick Bootloader Mods Currently none. OEM info # cat /proc/version Linux version 2.6.36-svn14734 (root@SWRD) (gcc version 3.4.2) #1 Thu Mar 10 15:30:34 CST 2016 # cat /proc/cmdline es=1 root=/dev/ram0 console=ttyS0 # cat /proc/cpuinfo system type : Ralink RT63165 SOC processor : 0 cpu model : MIPS 34Kc V5.5 BogoMIPS : 465.30 wait instruction : yes microsecond timers : yes tlb_entries : 32 extra interrupt vector : yes hardware watchpoint : yes, count: 4, address/irw mask: [0x0004, 0x044c, 0x0ff8, 0x0953] ASEs implemented : mips16 dsp mt shadow register sets : 1 core : 0 VCED exceptions : not available VCEI exceptions : not available # free total used free shared buffers Mem: 61400 30212 31188 0 0 Swap: 0 0 0 Total: 61400 30212 31188 # cat /proc/mtd dev: size erasesize name mtd0: 00800000 00010000 "ALL" mtd1: 00030000 00010000 "Bootloader" mtd2: 00010000 00010000 "Config" mtd3: 00010000 00010000 "Factory" mtd4: 007b0000 00010000 "Kernel" Bootlogs OEM bootlog U-Boot 1.1.3 (Nov 23 2012 - 12:00:39) Board: Ralink APSoC DRAM: 64 MB relocate_code Pointer at: 83f18000 OpenWrt bootlog COPY HERE THE BOOTLOG ONCE OPENWRT IS INSTALLED AND RUNNING Notes Tags How to add tags ramips, rt6856, 8Flash, 64RAM, 1port, FastEthernet, 1NIC, 1WNIC, 802.11abgn, DetachableAntenna, MIPS, MIPS32, 34K, Unsupported devices This website uses cookies. By using the website, you agree with storing cookies on your computer. Also you acknowledge that you have read and understand our Privacy Policy. If you do not agree leave the website.OKMore information about cookies ramips rt6856 8Flash 64RAM 1port fastethernet 1nic 1wnic 802.11abgn detachableantenna mips mips32 34k Unsupported devices Last modified: 2021/05/28 03:42by danitool
