Use USB QMI or CDC-MBIM capable dongles for WWAN connection

Many currently-available cellular modems use USB CDC-MBIM standard device class (or the ancestor Qualcomm's QMI) to interact with the host system, e.g. with an OpenWrt router or a PC or a smartphone with WWAN connectivity. For your information, QMI is a proprietary protocol by Qualcomm which has been used by many devices from different vendors as well. MBIM is a standard protocol (inspired by QMI) from the USB Implementer's Forum. Differences between QMI and CDC-MBIM are mostly related to stripping the Qualcomm-specific features while adding support for generic vendor-specific extensions.

The Linux driver for QMI is called qmi_wwan, the driver for CDC-MBIM is called cdc_mbim. They both rely on the common cdc_wdm driver.

This recipe explains how to setup and configure OpenWrt for using cellular USB modems for WWAN connection, using either MBIM or QMI interfaces.

The same applies to modems connected to external USB ports and internal USB-capable M.2(NGFF) or miniPCIe slots.

You may want to checkout the mwan3 (Multi WAN load balancing/failover) package to use this simultaneously with other connections to the Internet.

Also, see the Optimization sub-section of this page, for certain issues with MTU and Bufferbloat management.

Many modern USB modems may operate in different modes. If your modem provides only serial interface(s) like /dev/ttyUSBx PPP - please refer to the 3GDongle Wiki Page on how to use 3g/UMTS USB Dongle for WAN connection. For more information about other protocols commonly used:

• QMI, see below on this page.
• CDC-MBIM, see below on this page.
• CDC-NCM, see Use USB CDC-NCM capable dongles for WWAN connection
• CDC-ECM, see Use USB CDC-ECM capable dongles for WWAN connection
• RNDIS, see Use USB serial modem dongles for WWAN connection

If it is possible to switch your modem to provide QMI or MBIM interface - then this article is for you.

1. Install OpenWrt release image for your device.

2. Complete Steps OpenWrt Configuration

3. Router should be turned on and connected to the Internet to get the needed packages. Please refer to: Internet Connection.

• You can often use the firmware-selector (builder) website, to make an image with the additional modules mentioned below.

To make use of QMI protocol, packages kmod-usb-net-qmi-wwan (driver) and uqmi (control utility) are needed, additionally luci-proto-qmi (for web interface support). For MBIM protocol, the package equivalents are kmod-usb-net-cdc-mbim, umbim, and luci-proto-mbim. Additionally, there is the ModemManager package, which takes control of the modem using the MBIM protocol, and adds a web interface page luci-app-modemmanager.

Support for the particular modem's serial interfaces (/dev/ttyUSBx) - require packages such as kmod-usb-serial-option, kmod-usb-serial-qualcomm or kmod-usb-serial-sierrawireless, depending on the modem. They are needed to interact with the modem using AT commands, for configuration purposes or to be able to send/receive SMS and USSD.

A terminal program like picocom will be needed to interactively send & receive AT commands. picocom /dev/ttyUSB2 is the typical shell command to start communicating with AT commands. 1

1. Web protocol support (LuCI) as stated earlier - install luci-proto-qmi for QMI or luci-proto-mbim for MBIM, to use the web interface to configure and visualize your connection.

2. Install usb-modeswitch package only if that is needed for switching the modem into a “working” state. More about: USB mode switch

3. If available, add support for storage component of your modem - refer to: USB Storage

4. Additional utilities for modems that can be added to an Openwrt build, are available at https://github.com/koshev-msk/modemfeed repository. To add them to your build environment, edit 'feeds.conf.default', add the line: src-git modemfeed https://github.com/koshev-msk/modemfeed.git. It includes a luci-app-modeminfo, that requires you also select the underlying component, like modeminfo-qmi, in your build configuration. This functions similar to luci-app-modemmanager, but unlike modemmanager, aims to simply display the cellular connection information, rather than controlling the modem connection aggressively/directly.

5. There is a lot of additional, useful information that can save you a lot of time, at this repository https://github.com/danielewood/sierra-wireless-modems, if you have a Sierra modem. If you have a Quectel device, their support forum is a decent location to find information.

1. Install all the needed packages either in LuCI → System → Software or via command line: See Modem Preparation below, if you have picocom serial interface working, but are not sure what mode the modem is in.

• if the modem is in QMI mode:

root@OpenWrt:~# opkg update
root@OpenWrt:~# opkg install kmod-usb-net-qmi-wwan uqmi luci-proto-qmi kmod-usb-serial-option picocom

• if the modem is in MBIM mode:

root@OpenWrt:~# opkg update
root@OpenWrt:~# opkg install kmod-usb-net-cdc-mbim umbim luci-proto-mbim kmod-usb-serial-option picocom

If your have not enough space on your device - think about upgrading your hardware or installing Rootfs on External Storage (extroot). Refer to your router wiki page or forum thread for possibility and instructions.

2. Reboot the router by executing reboot on the console.

3. Check if you got a new device:

root@OpenWrt:~# ls -l /dev/cdc*

crw-r--r--    1 root     root      180, 176 Oct  1 12:03 /dev/cdc-wdm0

If there is no such device found - try to get more details:

• Open System Log from LuCI web interface and see what it shows regarding newly discovered USB device(s)
• execute dmesg on the console and see if any relevant information is present in the kernel log
• check the details about USB devices detected by the system by running cat /sys/kernel/debug/usb/devices on the console:

[...]
T:  Bus=01 Lev=01 Prnt=01 Port=00 Cnt=01 Dev#=  2 Spd=480  MxCh= 0
D:  Ver= 2.00 Cls=ef(misc ) Sub=02 Prot=01 MxPS=64 #Cfgs=  1
P:  Vendor=2c7c ProdID=0306 Rev= 3.10
S:  Manufacturer=Quectel
S:  Product=EP06-E
S:  SerialNumber=0123456789ABCDEF
C:* #Ifs= 5 Cfg#= 1 Atr=a0 MxPwr=500mA
I:* If#= 0 Alt= 0 #EPs= 2 Cls=ff(vend.) Sub=ff Prot=ff Driver=option
E:  Ad=81(I) Atr=02(Bulk) MxPS= 512 Ivl=0ms
E:  Ad=01(O) Atr=02(Bulk) MxPS= 512 Ivl=0ms
I:* If#= 1 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=option
E:  Ad=83(I) Atr=03(Int.) MxPS=  10 Ivl=32ms
E:  Ad=82(I) Atr=02(Bulk) MxPS= 512 Ivl=0ms
E:  Ad=02(O) Atr=02(Bulk) MxPS= 512 Ivl=0ms
I:* If#= 2 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=option
E:  Ad=85(I) Atr=03(Int.) MxPS=  10 Ivl=32ms
E:  Ad=84(I) Atr=02(Bulk) MxPS= 512 Ivl=0ms
E:  Ad=03(O) Atr=02(Bulk) MxPS= 512 Ivl=0ms
I:* If#= 3 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=00 Prot=00 Driver=option
E:  Ad=87(I) Atr=03(Int.) MxPS=  10 Ivl=32ms
E:  Ad=86(I) Atr=02(Bulk) MxPS= 512 Ivl=0ms
E:  Ad=04(O) Atr=02(Bulk) MxPS= 512 Ivl=0ms
I:* If#= 4 Alt= 0 #EPs= 3 Cls=ff(vend.) Sub=ff Prot=ff Driver=qmi_wwan
E:  Ad=89(I) Atr=03(Int.) MxPS=   8 Ivl=32ms
E:  Ad=88(I) Atr=02(Bulk) MxPS= 512 Ivl=0ms
E:  Ad=05(O) Atr=02(Bulk) MxPS= 512 Ivl=0ms

See Troubleshooting Section of this page for more information.

Unlike conventional interfaces, cell modems have to be 'prepared' to be in the right mode. They may come shipped in one mode, but you prefer to use another. Or your needs require a different mode.

If QMI or MBIM interface is not exposed by the modem initially you may need to switch it to another mode or composition by using USB mode switch tool or a vendor-specific AT command.

You can read further about AT commands for your modem. Typically, the command is 'picocom /dev/ttyUSB2'.

More recent modems are set by default to MBIM or QMI mode.

This is an example of switching modes for popular Quectel modems (these are manufacturer-specific, don't expect them to work on devices from other manufacturers):

AT+QCFG="usbnet"	# check the current mode
AT+QCFG="usbnet",0	# set QMI or RMNET mode, or
AT+QCFG="usbnet",1	# set ECM mode, or
AT+QCFG="usbnet",2	# set MBIM mode

Reset the modem to apply changes - power toggle it or send AT+CFUN=1,1 command.

The equivalent commands for Sierra Wireless (SEMTECH) modems:

AT!ENTERCND="A710"	# enter the configuration mode allowing you to make certain administrative changes
AT!USBCOMP?		# check the current mode
AT!USBCOMP=1,1,10D	# set QMI mode, or
AT!USBCOMP=1,1,100D	# set MBIM mode
AT!RESET		# Reset and apply the changes

Although the APN, Authentication Type and PDP (IPv4, v6 or both) are set through the LuCI web interface, it may be worth familiarizing yourself with the list of stored PDP Contexts and APNs configured on the modem.

To see the stored values, use a standard 3GPP command: AT+CGDCONT?

Generic example:

AT+CGDCONT?
+CGDCONT: 1,"IPV4V6","internet",...
+CGDCONT: 2,"IPV4V6","ims",...
+CGDCONT: 3,"IPV4V6","sos",...

Typically, but not always, context #1 is used for the Internet connection. On Verizon, it's Context 3, and Context 1 is used for IMS (Messaging services, SMS).

If it is not configured with the correct information (IP type and APN), it is recommended to set the desired parameters. Example:

AT+CGDCONT=1,"IP","internet"

Replace IP with IPV4V6 or IPV6 if necessary and use your APN instead of internet.

More specific examples: For T-Mobile:

at+cgdcont=1,"ipv4v6","fast.t-mobile.com"

For Verizon (your Verizon-specific firmware, e.g. Sierra, should already have these):

AT+CGDCONT=1,"IPV4V6","vzwims" # set first context for vzwims (SMS)
AT+CGDCONT=2,"IPV4V6","vzwadmin" # required for OTA compliance with Verizon network
AT+CGDCONT=3,"IPV4V6","vzwinternet" # set 3rd context for data (internet)
AT+CGDCONT=4,"IPV4V6","vzwapp" # required for compliance with Verizon network

Verizon has strict guidelines on how the PDP Contexts are supposed to be set-up, all the way back from at least 10 years ago (2017). See more references here and here and here.

* Anyone not running those PDP Contexts, in that order, with a Verizon SIM, and attempting to connect to Verizon, may eventually get disconnected from the network and be unable to reconnect. One of the recoveries is to flash the vendor-specific approved firmware.

* There is a bug in Openwrt. When selecting the PDP Context ID other than '1' (default), like '3' - per Verizon requirements, Openwrt incorrectly writes the information to the '1' context anyway. Search the qmi.sh script for --modify-profile “3gpp,1”. The “3gpp,x” part of the command, is writing to the PDP Context ID (Openwrt calls it 'APN Index'), where the ID is the x. Openwrt Luci calls the PDP Context ID, the APN Profile Index. That corresponds to the underlying /etc/config/network where the term option profile '1' and option v6profile '1' is used in config interface 'qmi'.

For an alternative method, see Manual validation section below.

While in the terminal, check the modem firmware version with ATI, and see if there is an upgrade available on the manufacturer's support website or forum. Oftentimes, it improves performance. But on some modems, it may have unintended consequences. It is best, but not necessary, if you have your original firmware available to go back to.

[QMI]: Assuming luci-proto-qmi package is installed, navigate to Network → Interfaces, then Add new interface… → Protocol: QMI Cellular

[MBIM]: Assuming luci-proto-mbim package is installed, navigate to Network → Interfaces, then Add new interface… → Protocol: MBIM Cellular

[Common]:

Select Interface “cdc-wdm0” in the drop-down. If it is not available there, check if the corresponding driver (kmod-usb-net-*) is loaded, reset the modem if its mode has recently been changed.

Enter your APN and select the IP type as instructed by the carrier. Don't set IP type to IPV4V6 until you're 100% sure that provider supports IPv6, that is critical in QMI mode.

Note: For IPv6 mode it is recommended to enable the IPv6 options (see further down).

Assign the firewall zone (wan) on 'Firewall Settings' tab. You may need to enable masquerading (checked ON by default for the pre-defined 'wan' zone), depending on the provider, if you do not get a -PD (assigned set of IPv6 addresses for your network). Verizon, T-Mobile and other major networks now do Prefix Delegation. Otherwise, it's called 'IPv6 Masquerading', under the 'Advanced Settings' tab. If you are not going to use MSS Clamping, which enables certain firewall rules, do not check it here. There is a work-around for Quectel devices that crash when their MTU is set, which MSS Clamping is dependent on. It is below ('MTU Issues' under Troubleshooting & Optimization). Those alternate instructions turn on MSS Clamping without triggering the crash of the modem.

Instead of using the web interface, this is how the files can be manually edited:

Add new interface to /etc/config/network using a text editor like vi or nano:

Example:

config interface 'qmi'
        option proto 'qmi'
        option device '/dev/cdc-wdm0'
        option apn 'internet'
        option auth 'none'
        option pdptype 'ipv4v6'

Replace “qmi” with “mbim” if necessary to match the modem configuration. Make sure the APN name is one provided by your carrier.

Add the same interface name to the existing “wan” firewall zone in /etc/config/firewall:

config zone
    option name 'wan'
    [...]
    list network 'wwan'

QMI (and MBIM) interfaces could be manually configured in UCI using uci command line or text editor.

Here is a brief help about uqmi command line usage:

Usage: uqmi <options|actions>
Options:
  --single, -s:                     Print output as a single line (for scripts)
  --device=NAME, -d NAME:           Set device name to NAME (required)
  --keep-client-id <name>:          Keep Client ID for service <name>
  --release-client-id <name>:       Release Client ID after exiting
  --mbim, -m                        NAME is an MBIM device with EXT_QMUX support
  --timeout, -t                     response timeout in msecs

Services:                           dms, nas, pds, wds, wms

Actions:
  --get-versions:                   Get service versions
  --set-client-id <name>,<id>:      Set Client ID for service <name> to <id>
                                    (implies --keep-client-id)
  --get-client-id <name>:           Connect and get Client ID for service <name>
                                    (implies --keep-client-id)
  --sync:                           Release all Client IDs
  --start-network:                  Start network connection (use with options below)
    --apn <apn>:                    Use APN
    --auth-type pap|chap|both|none: Use network authentication type
    --username <name>:              Use network username
    --password <password>:          Use network password
    --ip-family <family>:           Use ip-family for the connection (ipv4, ipv6, unspecified)
    --autoconnect:                  Enable automatic connect/reconnect
    --profile <index>:              Use connection profile
  --stop-network <pdh>:             Stop network connection (use with option below)
    --autoconnect:                  Disable automatic connect/reconnect
  --get-data-status:                Get current data access status
  --set-ip-family <val>:            Set ip-family (ipv4, ipv6, unspecified)
  --set-autoconnect <val>:          Set automatic connect/reconnect (disabled, enabled, paused)
  --get-profile-settings <val,#>:   Get APN profile settings (3gpp, 3gpp2),#
  --get-default-profile <val>:      Get default profile number (3gpp, 3gpp2)
  --create-profile <val>            Create profile (3gpp, 3gpp2)
    --apn <apn>:                    Use APN
    --pdp-type ipv4|ipv6|ipv4v6>:   Use pdp-type for the connection
    --username <name>:              Use network username
    --password <password>:          Use network password
    --auth-type pap|chap|both|none: Use network authentication type
    --no-roaming false|true         To allow roaming, set to false
  --modify-profile <val>,#          Modify profile number (3gpp, 3gpp2)
    --apn <apn>:                    Use APN
    --pdp-type ipv4|ipv6|ipv4v6>:   Use pdp-type for the connection
    --username <name>:              Use network username
    --password <password>:          Use network password
    --auth-type pap|chap|both|none: Use network authentication type
    --no-roaming false|true         To allow roaming, set to false
  --get-current-settings:           Get current connection settings
  --get-capabilities:               List device capabilities
  --get-pin-status:                 Get PIN verification status
  --verify-pin1 <pin>:              Verify PIN1
  --verify-pin2 <pin>:              Verify PIN2
  --set-pin1-protection <state>:    Set PIN1 protection state (disabled, enabled)
    --pin <pin>:                    PIN1 needed to change state
  --set-pin2-protection <state>:    Set PIN2 protection state (disabled, enabled)
    --pin <pin2>:                   PIN2 needed to change state
  --change-pin1:                    Change PIN1
    --pin <old pin>:                Current PIN1
    --new-pin <new pin>:            New pin
  --change-pin2:                    Change PIN2
    --pin <old pin>:                Current PIN2
    --new-pin <new pin>:            New pin
  --unblock-pin1:                   Unblock PIN1
    --puk <puk>:                    PUK needed to unblock
    --new-pin <new pin>:            New pin
  --unblock-pin2:                   Unblock PIN2
    --puk <puk>:                    PUK needed to unblock
    --new-pin <new pin>:            New pin
  --get-iccid:                      Get the ICCID
  --get-imsi:                       Get International Mobile Subscriber ID
  --get-imei:                       Get International Mobile Equipment ID
  --get-msisdn:                     Get the MSISDN (telephone number)
  --reset-dms:                      Reset the DMS service
  --get-device-operating-mode       Get the device operating mode
  --set-device-operating-mode <m>   Set the device operating mode
                                    (modes: online, low_power, factory_test, offline
                                     reset, shutting_down, persistent_low_power,
                                     mode_only_low_power)
  --fcc-auth:                       Set FCC authentication
  --uim-verify-pin1 <pin>:          Verify PIN1 (new devices)
  --uim-verify-pin2 <pin>:          Verify PIN2 (new devices)
  --uim-get-sim-state:              Get current SIM state
  --uim-power-off:                  Power off SIM card
    --uim-slot:                     SIM slot [1-2]
  --uim-power-on:                   Power on SIM card
    --uim-slot:                     SIM slot [1-2]
  --set-network-modes <modes>:      Set usable network modes (Syntax: <mode1>[,<mode2>,...])
                                    Available modes: all, lte, umts, gsm, cdma, td-scdma
  --set-network-preference <mode>:  Set preferred network mode to <mode>
                                    Available modes: auto, gsm, wcdma
  --set-network-roaming <mode>:     Set roaming preference:
                                    Available modes: any, off, only
  --network-scan:                   Initiate network scan
  --network-register:               Initiate network register
  --set-plmn:                       Register at specified network
    --mcc <mcc>:                    Mobile Country Code (0 - auto)
    --mnc <mnc>:                    Mobile Network Code
  --get-plmn:                       Get preferred network selection info
  --get-signal-info:                Get signal strength info
  --get-serving-system:             Get serving system info
  --get-system-info:                Get system info
  --get-lte-cphy-ca-info:           Get LTE Cphy CA Info
  --get-cell-location-info:         Get Cell Location Info
  --get-tx-rx-info <radio>:         Get TX/RX Info (gsm, umts, lte)
  --list-messages:                  List SMS messages
    --storage <mem>:                Messages storage (sim (default), me)
  --delete-message <id>:            Delete SMS message at index <id>
    --storage <mem>:                Messages storage (sim (default), me)
  --get-message <id>:               Get SMS message at index <id>
    --storage <mem>:                Messages storage (sim (default), me)
  --get-raw-message <id>:           Get SMS raw message contents at index <id>
    --storage <mem>:                Messages storage (sim (default), me)
  --send-message <data>:            Send SMS message (use options below)
    --send-message-smsc <nr>:       SMSC number
    --send-message-target <nr>:     Destination number (required)
    --send-message-flash:           Send as Flash SMS
  --wda-set-data-format <type>:     Set data format (type: 802.3|raw-ip)
  --wda-get-data-format:            Get data format

MBIM configuration is very similar to QMI. Supported interface configuration options:

Here is a brief help about umbim command line:

root@OpenWrt:~# umbim help
Usage: umbim <caps|pinstate|unlock|home|registration|subscriber|attach|detach|connect|disconnect|config|radio> [options]
Options:
    -d <device>         the device (/dev/cdc-wdmX)
    -t <transaction>    the transaction id
    -n                  no close
    -v                  verbose

uqmi tool can talk to MBIM modems using --mbim or -m option on the command line.

Check the currently configured APN:

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --get-profile-settings 3gpp,1
{
        "apn": "internet",
        "pdp-type": "ipv4v6",
        "username": "",
        "password": "",
        "auth": "none",
        "no-roaming": false,
        "apn-disabled": false
}

Change the APN and/or IP type (an alternative method to using AT commands mentioned above):

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --set-device-operating-mode low_power
root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --modify-profile 3gpp,1 --apn internet --pdp-type=ipv4 --username="" --password="" --auth=none
root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --set-device-operating-mode online

where “internet” is the APN of your provider

Check network registration and signal strength:

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --get-serving-system
{
        "registration": "registered",
        "plmn_mcc": 123,
        "plmn_mnc": 45,
        "plmn_description": "OperatorName",
        "roaming": false
}

and

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --get-signal-info
{
        "type": "lte",
        "rssi": -71,
        "rsrq": -9,
        "rsrp": -94,
        "snr": 70
}

Check the connection status:

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --get-data-status
"disconnected"

To manually start the Internet connection issue a command:

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --start-network internet --autoconnect

where “internet” is the APN of your provider

Some providers will accept almost any APN, in this case using “internet” is fine.

Check the status:

root@OpenWrt:~# uqmi -d /dev/cdc-wdm0 --get-data-status
"connected"

--autoconnect key says that you want always be connected, once the modem is physically connected to the router and cellular network is in range. It will be kept after reboot.

In case you need additional authentication, please look at the possible arguments for uqmi utility:

  --start-network <apn>:            Start network connection (use with options below)
    --auth-type pap|chap|both|none: Use network authentication type
    --username <name>:              Use network username
    --password <password>:          Use network password
    --autoconnect:                  Enable automatic connect/reconnect
  --stop-network <pdh>:             Stop network connection (use with option below)
    --autoconnect:                  Disable automatic connect/reconnect

To check your balance or send any other AT commands, you need to have USB serial device like: /dev/ttyUSB0

If you have it (if not then install missing USB serial drivers), you can run in first terminal:

cat /dev/ttyUSB0

and in the second (*101# is my USSD code):

echo -ne 'AT+CUSD=1,"*101#",15\r\n' > /dev/ttyUSB0

You should see in first terminal USSD response.

WAN status is available in Dashboard and System→Overview in LuCI web interface. ModemManager is a managed QMI/MBIM interface that has a page showing signal strength and other values. There are also external packages like https://github.com/4IceG/luci-app-modemdata or https://github.com/4IceG/luci-app-3ginfo-lite for displaying modem status and https://github.com/4IceG/luci-app-sms-tool-js for SMS support.

Stability issues with the connection

Read-on, but also see the Optimization section, below.

Everything is okay but modem doesn't establish connection. What can I try?

You may want to try adding the argument --get-client-id wds and --set-client-id when running uqmi like:

wds=`uqmi -s -d /dev/cdc-wdm0 --get-client-id wds`
uqmi -d /dev/cdc-wdm0 --set-client-id wds,"$wds" --start-network your_apn

Moreover based on this article I discovered that need to reset my modem (tested on Dell Wireless 5804 413c:819b) in boot process, so you can try add the following commands in your /etc/rc.local:

/sbin/uqmi -d /dev/cdc-wdm0 --set-device-operating-mode offline
/sbin/uqmi -d /dev/cdc-wdm0 --set-device-operating-mode reset
/bin/sleep 20
/sbin/uqmi -d /dev/cdc-wdm0 --set-device-operating-mode online
/sbin/uqmi -d /dev/cdc-wdm0 --set-autoconnect enabled
/sbin/uqmi -d /dev/cdc-wdm0 --network-register

My router is not detecting the modem. What should I do?

Try the following commands:

usbmode -l

It should respond with a message about your USB device is detected. If it does, issue the next command. If it doesn't, you might want to get help from the forum.

usbmode -s

Then wait for the modem to get issued an IP from your ISP.

No serial or network device is present (/dev/ttyUSB, /dev/cdc-wdm)

You may need to install the missing packages

opkg install kmod-usb-net-qmi-wwan kmod-usb-serial-option kmod-usb-serial-qualcomm

As explained elsewhere, your modem might suffer regular or irregular disconnections. First, see the Optimization guide below.

Irregular disconnections might be caused by incorrect MSS/MTU settings, or the software and hardware of the modem, whose symptoms are generally loss of connectivity minutes after rebooting the router, very high latency and high packet loss on heavy load, modem software hanging and becoming irresponsive on certain events or during transmission of specific data. For these kind of situations, a firmware upgrade, watchdog script or watchcat package is recommended. See :docs:guide-user:network:wan:wwan:ltedongle#sample_cell_modem_wan_watchdog_script_basic_simple or watchcat

Regular disconnections (at specific times of the day, or after an exact number of hours) are generally when the mobile provider is force-issuing them. These should be normally handled transparently by the modem, but this may not the case that the modem handles it correctly. For this, you might want to perform a regular reboot of the only the modem, to keep it working. However, [as a contributor who has read ALL of Quectel's 300+ pages of modem documentation, and has had several of them, talked with others who have managed over 1000 quectel devices, and has been using them for years successfully with Openwrt] for another perspective, it may simply be an issue with your configuration. Chronically-bad stability issues, of the type mentioned, went away with use of pure QMI, and no MTU value assignment or APN assignment, besides selecting the correct SIM profile. [End comment]

If you find there is a specific period needed for restarting only the modem device, and you want to do it based on time instead of status of the connection, here is a sample script: For example, to perform a modem reboot every 24 hours (during the night) you can add this line to the cron:

0 3 * * *  echo -n -e 'AT+CFUN=1,1\r\n' > /dev/ttyUSB3

The modem will reboot, OpenWrt will detect the USB and CDC interfaces disappearing and reappearing again, and restart the WAN interface, effectively requesting a new connection to the network and acquiring a new IP.

While those above commands will do the described action, it's generally better to fix the stability issues, and probe the connection periodically with the advanced connectivity script, allowing it to log and take action as necessary.

The modem responds not_initialized during the QMI start-up process, producing a PIN_STATUS_FAILED error on the QMI Interface. But there is no PIN required (and pin1 value is blank). A workaround is editing the '/lib/netifd/proto/qmi.sh' script, at line 158, adding/editing the response 'not_initialized' instead of 'disabled'.

Cellular networks use an additional 80 bytes of encapsulation, beyond what ordinary ethernet networks have. Starting with how your actual data payload is called the MSS, and on ethernet, we have to add 40 bytes to get the MTU (1500), on cellular networks we have to make the MSS smaller, to make additional room for the 80 bytes of overhead that are part of added encapsulation protocols, that handle getting your data to it's destination, for an effective MTU on our cellular wan link of 1420. While Verizon uses 1428, and you could then adjust your values +8 accordingly, it's generally 1420 that is used for cellular networks. You may find that a slightly lower value, like 1400, works best in practical experience, even with an excellent quality connection. However, start with 1420 and see how it goes.

The examples below will all use 1420.

If you do not adjust your MTU at all, you may find unusual issues, like images not loading on certain sites, strange performance issues, and generally other odd behavior.

On IPv4, the router is responsible for altering packets that are too big. On IPv6, it's exclusively the client. So, on a typical legacy (non-IPv6) network, there is the assumption that if you simply set MSS Clamping on (in your WAN zone Firewall settings), and the Device Interface (WAN interface/device in Network→Interfaces) MTU is properly set, then everything will work.

There are two problems with that presumption:

1) There are known issues with the most common cellular modem chipsets firmware, found in routers, specifically the Quectel-brand modems. They run Quectel's implementation of Qualcomm's core firmware, and seem to exhibit a common problem, that if you set the MTU, or use a protocol that detects, and sets, the MTU, the modem chip locks-up within 2 minutes. Start with using the plain (and often the default support in firmware like ROOTER) QMI-support libraries (luci-proto-qmi), not ModemManager, and only set the minimal APN information, and select the PDP Context ID (called most recently the APN Profile Index in Openwrt Luci). If you specifically set the MTU, it can cause stability or crashes of the modem. This MTU crash issue also happens with the MBIM protocol or ModemManager, which in turn, uses MBIM, sets the MTU, and causes the same hard-lock of the chip, within minutes. see here for more info

2) MSS Clamping does not fix IPv6 issues other than TCP packets, related to cellular network MTU restrictions.

Since you still need to limit the MSS to fit inside the 1420 MTU for optimal performance, read-on:

• Use plain QMI protocol, and do not set the MTU at the Device Interface level
• To work-around the inability to set the Device Interface MTU directly, edit your /etc/config/firewall to include:

  config include
  	option path '/etc/firewall.user'
  	option fw4_compatible '1'

• In /etc/firewall.user, put:

  # Dealing with the MSS and MTU without adjusting the Device Interface MTU
  # For the outbound packets:
  nft add rule inet fw4 mangle_postrouting 'oifname "wwan0" tcp flags & (fin | syn | rst) == syn tcp option maxseg size set 1360'
  # For incoming / returning packets:
  nft add rule inet fw4 mangle_forward 'iifname "wwan0" tcp flags & (fin | syn | rst) == syn tcp option maxseg size set 1360'

This command sets the MSS maximum segment size to 1360, which when adding the IPV6 (40) and TCP (20) overhead, brings the MTU to 1420. It's almost identical to the MSS Clamping commands added to the firewall, but specifies a value (1360) instead of telling the firewall to read the wwan device's MTU and calculate an MSS. tracepath <destination>, without this firewall instruction, can help you determine an MTU suitable for you, although a value here of MSS 1360 is almost certainly the one to work on your cell network wan link. Note: You are setting the MSS, not the MTU. So 1360 + 40 + 20 = 1420.

The standard MSS Clamping option in the wan zone of the Luci Web Firewall interface, is meant to add a similar instruction, but calculate MSS from the Device Interface MTU, and does not have a field for setting a specific target MSS or MTU value. Therefore, when making the above firewall changes, uncheck MSS Clamping, equivalent to remarking-out or removing the mtu_fix '1' option for the WAN Zone in your /etc/config/firewall config. Be sure when you are finished to service firewall restart or restart it in the LuCI web interface.

IPv6 is not affected entirely by the above MTU command. IPv6 also requires the client, not the router, to react to 'packet too big' messages, so the client can send smaller packets. Further, in some cellular networks, they fail in handling proper PMTUD, failing to pass the 'packet too big' messages. So your client doesn't know to reduce it's IPv6 packet sizes. Fixing this is not automatic (yet) on Openwrt, even as of build r32579/v25.12: we need to add additional instructions for IPv6. Since we always know the maximum standard for cellular is an MTU of 1420, we need to make sure Openwrt's Router Advertisements -a part of IPv6- lets clients know the maximum MTU is 1420.

In particular, the main aspect is the option ra_mtu '1420' in the config dhcp 'lan' section of /etc/config/dhcp.

An example of a fully-functional IPv4 and IPv6 config dhcp 'lan' section of /etc/config/dhcp, on a recent build of Openwrt (r32579/v25.12), looks like:

config dhcp 'lan'
	option interface 'lan'
	option start '2'
	option limit '250'
	option leasetime '24h'
	option dhcpv4 'server'
	option dhcpv6 'server'
	option ra 'server'
	option ipv6_only_preferred '300'
	option force '1'
	option ra_preference 'medium'
	option ra_default '1'
	list ntp '192.168.1.1'
	list ntp '192.168.1.2'
	list ntp 'time.nist.gov'
	list ra_flags 'other-config'
	option ra_slaac '1'
	option dhcpv6_pd_preferred '1'
	option ra_mtu '1420'

This is directly from a router with an internal cellular modem, using a verizon sim (but using the smaller, more standard 1420 MTU). This has been tested on Sierra, Quectel, Verizon and TMOBILE. Both Verizon and T-Mobile also do issue /64 -PD Prefix Delegation, so your LAN clients can get a valid IPv6 address.

If you re-use this, the first 'list ntp' servers are your router's NTP Server. It should be turned on in your System settings. And the 1.1 should be changed to your router and 1.2 to a back-up Openwrt device on your network (or another NTP server). The 'time.nist.gov' should be modified to a regional NTP server of your choice, and an additional ipv6 address of an NTP server should be added. This configuration properly supports Android (SLAAC), Windows (DHCPv6) and IoT devices (many definitely need the ra_mtu). Use test-ipv6.run to check. There are issues with test-ipv6.com scripts, as of this writing, causing android devices to mis-report that IPv6 addresses are not being assigned. Another way to test ipv6 is with a curl -6 ifconfig.co command, from Termux or a shell. If it works, it will simply respond with your device's IPv6 address.

Continuing from the above ra_mtu issue, and related to it:

Because IPv6 also requires essential services to pass through your firewall, and Openwrt does not (yet) fully enable them by default, here are the additional firewall config rule rules concerning the wan zone: These are taken directly from a fully-functional router with a built-in cellular modem. All services, sites, apps, and devices work and load smoothly. All IPv4 and IPv6 issues have been overcome. This is the 'finished product', in production.

config rule
	option name 'Allow-ICMPv6-Input'
	option src 'wan'
	option proto 'icmp'
	option limit '100/sec'
	option family 'ipv6'
	option target 'ACCEPT'
	list icmp_type 'bad-header'
	list icmp_type 'destination-unreachable'
	list icmp_type 'echo-reply'
	list icmp_type 'echo-request'
	list icmp_type 'neighbour-advertisement'
	list icmp_type 'neighbour-solicitation'
	list icmp_type 'packet-too-big'
	list icmp_type 'router-advertisement'
	list icmp_type 'router-solicitation'
	list icmp_type 'time-exceeded'
	list icmp_type 'unknown-header-type'
	option limit_burst '10'

config rule
	option name 'Allow-ICMPv6-Forward-Ping'
	option src 'wan'
	option dest 'lan'
	option proto 'icmp'
	list icmp_type 'echo-request'
	option limit '10/second'
	option family 'ipv6'
	option target 'ACCEPT'
	option limit_burst '10'

config rule
	option name 'Allow-ICMPv6-Forward'
	option src 'lan'
	option dest 'wan'
	option proto 'icmp'
	option limit '10/second'
	option family 'ipv6'
	option target 'ACCEPT'
	list icmp_type 'bad-header'
	list icmp_type 'destination-unreachable'
	list icmp_type 'echo-reply'
	list icmp_type 'echo-request'
	list icmp_type 'neighbour-advertisement'
	list icmp_type 'neighbour-solicitation'
	list icmp_type 'packet-too-big'
	list icmp_type 'router-advertisement'
	list icmp_type 'router-solicitation'
	list icmp_type 'time-exceeded'
	list icmp_type 'unknown-header-type'
	option limit_burst '10'

Along with the above ra_mtu and firewall issues on IPv6, as of this writing, again using a recent build - r32579 / v25.12 - , Openwrt still fails to properly support cellular data links over QMI. Specifically, in the aspect of forming a default ipv6 route / dealing with the upstream provider IPv6 gateway information, which can be read with ifstatus qmi. To solve this, an additional script, /etc/hotplug.d/iface/90-qmi-ipv6-route, will pull the gateway information from the ifstatus qmi query, after connecting, and integrate the information into your routing table, so clients and the router can properly reach ipv6 sites.

As this needs ifstatus qmi to work, make sure that command works by itself from the shell. If your ipv6 / main qmi interface is called something else, make sure to modify the script accordingly.

#!/bin/sh
[ "$INTERFACE" = "qmi" ] || exit 0
[ "$ACTION" = "ifup" ] || exit 0

# Extract current gateway from route
GATEWAY=$(ifstatus qmi | jsonfilter -e '@.route[1].nexthop')
DEVICE=$(ifstatus qmi | jsonfilter -e '@.l3_device')

# Add default route
ip -6 route replace ::/0 via "$GATEWAY" dev "$DEVICE" metric 512

1) Create the script / file in the folder as shown. 2) Make sure to do a chmod +x 90-qmi-ipv6-route to make it executable.

• If you have provider tethering-related issues, e.g. bandwidth restrictions: in /etc/firewall.user add

# For the outbound packets:
nft add rule inet fw4 mangle_postrouting oifname wwan0 ip ttl set 64
nft add rule inet fw4 mangle_postrouting oifname wwan0 ip6 hoplimit set 64
# And as it's bi-directional, for the returning / inbound packets:
nft add rule inet fw4 mangle_forward iifname wwan0 ip ttl set 64
nft add rule inet fw4 mangle_forward iifname wwan0 ip6 hoplimit set 64

Note: 64 is the value given here, although your particular cellular service provider may require a different value. Other users have reported successful values online, and you can do an internet search to find them.

Along with the above firewall modifications, you may find that your LAN clients are still unreachable, even though your cellular provider issues -PD addresses in a range that is public, and your LAN client is clearly getting a public IPv6 address (curl -6 ifconfig.co). Various carriers (Verizon being one) use upstream firewall rules that block inbound access to their typical cellular network clients. There is no workaround for this, besides running 6in4 or some kind of remote VPS or other method of directing inbound traffic through a tunnel, to bypass carrier security restrictions.

• Quectel modems in general have an earned reputation for having firmware stability issues and design flaws. However, if you figure out how to work around them, they work quite well. If you run into frustrating issues specifically with regards to the cell connection/modem, it is not likely to be Openwrt. The modem runs its own closed-source firmware, like a router within a router. What it means is that, depending on how the mobile provider do it's IP assignment and handles connectivity, you might suffer disconnections after some time (generally a fixed number of hours like 2, 6, 24, 48 hours). For the moment, OpenWrt does not have a built-in routine to handle these modem issues, so you might want to set a periodic reboot of the modem itself, or add a watchdog script to restart the WAN / wwan0 / qmippp interface, or if needed, reboot the router.

Here is a wan_watchdog.sh script that tests the connection, and if it receives no response from several well-known DNS providers, it can:

1. Tell the modem to soft-off.
2. Tell the modem to soft-on (boot up).
3. Restart the interface, and
4. Reboot the router (if everything prior was unsuccessful).

• You will need to add the package fping.
• Consider using the more advanced connectivity connection script.
• To begin, edit your /etc/rc.local:

sleep 45 # you may have to lengthen or shorten this 45 second-delay, depending on how much time it takes for the wwan0 (cell connection modem) to link to the cell provider (radio tower) and establish an uplink (internet connection).
service sysntpd restart # Overcomes a NTP time issue (wrong time) issue after boot, due to lag time in the 4G connection coming up.
/root/wan-watchdog.sh & # The ampersand is important! Reboots will not work without it.
exit 0

• Save the following as 'wan-watchdog.sh' in your /root/. Make it executable (chmod +x wan-watchdog.sh)

#!/bin/sh

#wan-watchdog.sh v.20250326

check_fping() {
    # Run the fping command
    fping --alive --interval=400 --count=5 --fast-reachable=1 --addr 1.1.1.1 9.9.9.8 8.8.8.8 2001:4860:4860::8888 2620:fe::fe
}

#call from rc.local with /root/wan_watchdog.sh &
#bootscript startup. wait 360 seconds after restart before checking connection.
echo "Sleeping x seconds (60-180 typically). Initial startup after boot"
sleep 200
echo "Script started. Router booted on $(date)"
echo "Script startup, router booted on $(date)" >> /root/wan_reset_log.txt
#ping x times to see if common DNS servers are accessible.
#if at least one of them is responsive, pause 60 seconds, and try again.

echo "Entering ping-testing loop:"
CONNECTION="1"
while [[ $CONNECTION -gt 0 ]]; do
	echo "Value of CONNECTION so-far is:" $CONNECTION
	echo "Pinging a variety of well-known ipv4 and ipv6 addresses..."
	# ONE site success is enough. All of them failing, will cause corrective actions.
	if check_fping ; then
			echo "Successful response. Waiting 60 seconds and trying again."
			CONNECTION="1"
			sleep 60
		else
			echo "All Fpings failed."
			echo "All Fpings failed. Attempting to restart wwan interface on $(date)" >> /root/wan_reset_log.txt
			echo "Turning off the qmippp wwan interface in 5 seconds.."
			sleep 5
			echo "ifdown qmippp"
			ifdown qmippp
			echo "Wait 5 seconds then bringing up the qmippp interface.."
			sleep 5
			echo "ifup qmippp"
			ifup qmippp
			echo "Wait 45 seconds to give the modem time to reconnect..."
			sleep 45 # give the modem time to reconnect (takes 25 seconds for a typical QMI Quectel config, longer with VPN added)
			if check_fping ; then
				echo "SUCCESS: Quectel modem wwan restart worked, no need for reboot" >> /root/wan_reset_log.txt
				echo "SUCCESS: Quectel modem wwan restart worked, no need for reboot"
				CONNECTION="1"
			else
				echo "FAILURE: reboot required. Rebooting router..." >> /root/wan_reset_log.txt
				echo "FAILURE: reboot required. Rebooting..."
				sleep 5
				CONNECTION="0"
			fi
		fi
done
reboot

If you need to edit this script, while your router is running, first stop it by doing a ps | grep wan, and you'll see the process ID. Then do a kill (id), then nano wan-watchdog.sh. When finished, do a /root/wan-watchdog.sh & and the script will execute in the background (you can close the shell/ssh session).

The sleep delay timer, and then the NTP service restart, in the /etc/rc.local script above, corrects a common issue issue on Openwrt routers with internal cellular modem chips, where since most router-boards do not have a battery-backup for their clock, to maintain correct time & date between reboots, they have to pull the time from the internet (upstream), every time they power-up. Ordinarily, the WAN on a cell-modem router takes 30-45 seconds to connect, and time-retrieval services (NTPd) start before an upstream provider (internet) connection is established. Openwrt devices with built-in modems, can thus have the wrong time, initially. If you do not need the delay and ntpd restart, it does not negatively affect your router. The Openwrt device will eventually get the correct time, however, without this command, the initial boot time, e.g. for logging messages (the wan-watchdog.sh script) would be incorrect, leading to startup times and dates in the log that are not correct, hindering trouble-shooting.

See Wireguard Extra's more advanced connectivity monitoring script.
