Dataentry
- Device Type:
- WiFi Router
- Brand:
- GL.iNet
- Model:
- GL-B3000 (Marble)
- FCCID:
- https://fcc.io/2AFIW-B3000
- Availability:
- Available 2025
- Where available:
- gl-inet.com, amazon.com, aliexpress.com
- Supported Since Commit:
- https://git.openwrt.org/?p=openwrt/openwrt.git;a=commit;h=3307fe8ee4cf8ee52cefd03feb97f1d826253eeb
- Supported Since Rel:
- 25.12.0
- Supported Current Rel:
- 25.12.3
- Gluon support:
- unknown
- Target:
- qualcommax
- Subtarget:
- ipq50xx
- Package architecture:
- aarch64_cortex-a53
- Bootloader:
- U-Boot
- CPU:
- Qualcomm IPQ5018
- CPU Cores:
- 2
- CPU MHz:
- 1000
- Flash MB:
- 128NAND
- RAM MB:
- 512
- Ethernet 100M ports:
- -
- Ethernet 1Gbit ports:
- 3
- Ethernet 2.5Gbit ports:
- -
- Ethernet 5Gbit ports:
- -
- Ethernet 10Gbit ports:
- -
- SFP ports:
- -
- SFP+ ports:
- -
- Switch:
- Qualcomm Atheros QCA8337
- VLAN:
- Yes
- Modem:
- -
- WLAN Hardware:
- Qualcomm IPQ5018, Qualcomm QCN6102
- WLAN 2.4GHz:
- b/g/n/ax
- WLAN 5.0GHz:
- a/n/ac/ax
- WLAN 6.0GHz:
- -
- WLAN 60.0GHz:
- -
- WLAN Comments:
- MIMO 2x2:2 on both bands
- WLAN driver:
- ath11k
- Detachable Antennas:
- -
- Bluetooth:
- -
- miniPCI ports:
- -
- USB ports:
- -
- SATA ports:
- -
- Video ports:
- -
- Audio ports:
- -
- Phone ports:
- -
- Serial:
- Yes
- Serial connection parameters:
- 115200 / 8N1
- Serial connection voltage:
- 3.3v
- JTAG:
- ¿
- LED count:
- 2
- Button count:
- 1
- GPIOs:
- ¿
- Power Supply:
- 12V, 1.5A via barrel
- Outdoor:
- No
- OpenVPN performance:
- 30
- Wireguard performance:
- 190
- Device Page:
- gl-b3000
- OWrt Forum Topic URL:
- https://forum.openwrt.org/t/ipq5018-glinet-b3000-info/210771/
- Forum search:
- GL-B3000
- Git search:
- GL-B3000
- WikiDevi URL:
- https://techinfodepot.shoutwiki.com/wiki/GL.iNet_GL-B3000_(Marble)
- OEM Device Homepage URL:
- https://www.gl-inet.com/products/gl-b3000/
- Firmware OEM Stock URL:
- https://dl.gl-inet.com/router/b3000/
- Firmware OpenWrt Install URL:
- https://downloads.openwrt.org/releases/25.12.3/targets/qualcommax/ipq50xx/openwrt-25.12.3-qualcommax-ipq50xx-glinet_gl-b3000-squashfs-factory.img
- Firmware OpenWrt Upgrade URL:
- https://downloads.openwrt.org/releases/25.12.3/targets/qualcommax/ipq50xx/openwrt-25.12.3-qualcommax-ipq50xx-glinet_gl-b3000-squashfs-sysupgrade.bin
- Firmware OpenWrt snapshot Install URL:
- https://downloads.openwrt.org/snapshots/targets/qualcommax/ipq50xx/openwrt-qualcommax-ipq50xx-glinet_gl-b3000-squashfs-factory.img
- Firmware OpenWrt snapshot Upgrade URL:
- https://downloads.openwrt.org/snapshots/targets/qualcommax/ipq50xx/openwrt-qualcommax-ipq50xx-glinet_gl-b3000-squashfs-sysupgrade.bin
- Installation method(s):
- GL.Inet installation, see git-commit
- Recovery method(s):
- see git-commit
- Picture:
,
